More than 1150 flash cards, practice questions, and quick reference sheets for the QOS exam 642-642, CVOICE exam 642-432, and CIPT exam 642-443
Are you ready to take the QOS, CVOICE, or CIPT exam for the Cisco IP Telephony certification? You learned the concepts, you have the experience to put them into real-world use, and now you want to practice, practice, practice until exam time. Cisco IP Telephony Flash Cards and Exam Practice Pack gives you three methods of proven, late-stage Cisco IP Telephony exam preparation in one package.
Test Engine
The 600+ question exam engine includes both practice and study modes.
Flash Cards
More than 450 flash cards in PC, handheld, and print formats are available in customized sets.
Quick Reference Sheets
All exam topics are included in 100+ graphical quick reference sheets.
Cisco IP Telephony Flash Cards and Exam Practice Pack is part of a recommended learning path from Cisco Systems that includes simulation and hands-on training from authorized Cisco Learning Partners and self-study products from Cisco Press. To find out more about instructor-led training, e-learning, and hands-on instruction offered by authorized Cisco Learning Partners worldwide, please visit www.cisco.com/go/authorizedtraining.
Companion CD-ROM
The CD-ROM contains 450+ flash cards and 600+ practice test questions. Flash cards are downloadable to Palm OS and most 2002/2003 Pocket PC handheld devices. CD-ROM test engine powered by www.boson.com. Boson Software is a Cisco Learning Partner.
Minimum System Requirements
Windows 98, Me, 2000 Pro, or XP
Acrobat Reader 5.0 or higher
Internet Explorer 5.5 or higher
16 MB RAM for Windows 98 and Me;
64 MB RAM for Windows 2000 Pro and XP
800 x 600 resolution or higher
256 or more colors
Internet access for “instant” registration
Optional: Palm or Palm OS-compliant handheld device; Pocket PC handheld device
The networks of yesteryear physically separated voice, video, and data traffic. Literally, these traffic types flowed over separate media (for example, leased lines or fiber-optic cable plants). Today, however, network designers are leveraging the power of the data network to transmit voice and video, thus achieving significant cost savings by reducing equipment, maintenance, and even staffing costs.
The challenge, however, with today’s converged networks is that multiple applications are contending for bandwidth, and some applications such as, voice can be more intolerant of delay (that is, latency) than other applications such as, an FTP file transfer. A lack of bandwidth is the overshadowing issue for most quality problems.
When a lack of bandwidth exists, packets can suffer from one or more of the following symptoms:
*
Delay—Delay is the time that is required for a packet to travel from its source to its destination. You might witness delay on the evening news, when the news anchor is talking through satellite to a foreign news correspondent. Because of the satellite delay, the conversation begins to feel unnatural.
*
Jitter—Jitter is the uneven arrival of packets. For example, consider that in a Voice over IP (VoIP) conversation, packet 1 arrives. Then, 20 ms later, packet 2 arrives. After another 70 ms, packet 3 arrives, and then packet 4 arrives 20 ms behind packet 3. This variation in arrival times (that is, variable delay) is not dropping packets, but this jitter can be interpreted by the listener as dropped packets.
*
Drops—Packet drops occur when a link is congested and a buffer overflows. Some types of traffic, such as User Datagram Protocol (UDP) traffic (for example, voice), are not retransmitted if packets are dropped.
Fortunately, quality of service (QoS) features that are available on Cisco routers and switches can recognize your “important” traffic and then treat that traffic in a special way. For example, you might want to allocate 128 kbps of bandwidth for your VoIP traffic and also give that traffic priority treatment.
Consider water that is flowing through a series of pipes with varying diameters. The water’s flow rate through those pipes is limited to the water’s flow rate through the pipe with the smallest diameter. Similarly, as a packet travels from its source to its destination, its effective bandwidth is the bandwidth of the slowest link along that path.
Figure 1Figure 1
Because your primary challenge is a lack of bandwidth, the logical question is, “How do you increase available bandwidth?” A knee-jerk response to that question is often, “Add more bandwidth.” Although adding more bandwidth is the best solution, it comes at a relatively high cost.
Compare your network to a highway system in a large city. During rush hour, the lanes of the highway are congested, but the lanes can be underutilized during other periods of the day. Instead of just building more lanes to accommodate peak traffic rates, the highway engineers add carpool lanes. Cars with two or more riders can use the reserved carpool lane. These cars have a higher priority on the highway. Similarly, you can use QoS features to give your mission-critical applications higher-priority treatment in times of network congestion.
Some of the QoS features that can address issues of delay, jitter, and packet loss include the following:
*
Queuing—Queuing can send higher-priority traffic ahead of lower-priority traffic and make specific amounts of bandwidth available for those traffic types. Examples of queuing strategies that you consider later in these Quick Reference Sheets include the following:
o
Priority Queuing (PQ)
o
Custom Queuing (CQ)
o
Modified Deficit Round Robin (MDRR) queuing
o
Weighted Fair Queuing (WFQ)
o
Class-Based WFQ (CB-WFQ)
o
Low Latency Queuing (LLQ)
*
Compression—By compressing a packet’s header or payload, fewer bits are sent across the link. This effectively gives you more bandwidth.
